Depending on the BIOS settings, the shared LAN connector may also
be used as a management LAN connector. For more information, see
the corresponding BIOS Setup Utility reference manual.
Some of the devices connected require special software (e.g. drivers)
(see documentation for the connected device).
16.2.3.2 ID, CSS and Global Error indicators
Figure 294: ID, CSS and Global Error indicators
1 ID indicator, Global Error indicator,
CSS indicator
If CSS and Global Error indicators are located in the same place on the
I/O panel of the server, also check the indicators on the front panel to
determine if a CSS or Global Error event has been detected.
For more information on detected errors, see the System Event Log or
use the ServerView Operations Manager or iRMC web interface.
ID indicator (1)
See also "iRMC-related status signals" on page 452.
Appendix A
450 Upgrade and Maintenance Manual RX2520 M5
