Removing the defective 2.5-inch PCIe SSD module
▶
Remove the PCIe SSD module, see "Removing a 2.5-inch PCIe SSD
module" on page 183.
▶
If applicable, remove the PCIe SSD from the installation frame, see
"Handling HDDs or SSDs without installation frame" on page
125.
Installing the new 2.5-inch PCIe SSD module
▶
If applicable, install the PCIe SSD in the installation frame, see "Handling
HDDs or SSDs without installation frame" on page 125.
▶
Install the PCIe SSD module, see "Installing a 2.5-inch PCIe SSD module"
on page 181.
Concluding steps
▶
If applicable, "Switching on the server" on page 57.
▶
If applicable, rescan available devices from your OS, see the "NVMe User
Guide".
7.5.8 Replacing a 8x 2.5-inch HDD backplane
Your server can be equipped with up to three HDD backplanes. The
replacing procedure is always the same.
Field Replaceable Unit
(FRU)
Hardware: 15 minutes
Tools: Flat screw driver
Preliminary steps
▶
"Locating the defective server" on page 43
.
▶
"Suspending BitLocker functionality" on page 65.
▶
"Shutting down the server" on page 45.
Hard disk drive (HDD) / solid state disk (SSD)
RX2520 M5 Upgrade and Maintenance Manual 185
