11 Processor (CPU)
11.1
Safety notes
CAUTION
▶
Do not install unsupported CPUs. For more information on
supported CPUs, see "Basic information" on page 269.
▶
Circuit boards and soldered parts of internal options are exposed
and can be damaged by static electricity. Always discharge static
build-up (e.g. by touching a grounded object) before handling
electrostatic sensitive devices (ESDs).
▶
Do not touch the circuitry on boards or soldered parts. Hold circuit
boards by their metallic areas or edges.
▶
When removing or installing CPUs, be careful not to touch or bend
the spring contacts on the CPU sockets.
▶
Never touch the underside of the CPUs. Even minor soiling such as
grease from the skin can impair the CPU’s operation or destroy the
CPUs.
▶
For more information, see "Important information" on page 29
.
11.2 Basic information
The system board D3386 of
fers two sockets for Intel Xeon CPUs.
RX2520 M5 Upgrade and Maintenance Manual 269
