Figure 135: Installing the slot cover
▶
Insert a slot cover into the unused PCI slot opening.
▶
Fasten the slot cover with the screw (see circle).
Concluding steps
▶
"Reassembling" on page
51.
▶
"Connecting the power cord" on page
56.
▶
"Switching on the server" on page 57.
▶
"Resuming BitLocker functionality" on page 88.
9.5.3 Replacing an expansion card
Upgrade and Repair Unit
(URU)
Hardware: 5 minutes
Software: 5 minutes
Tools: Phillips PH2 / (+) No. 2 screw driver
Expansion cards and backup units
238 Upgrade and Maintenance Manual RX2520 M5
