Up to two FBUs or one FBU and one Dual microSD 64GB Enterprise can be
installed in the system.
Depending on the used controller different FBUs are available.
9.6.2
Installing an FBU
Upgrade and Repair Unit
(URU)
Hardware: 5 minutes
Tools: tool-less
Figure 141: Positions of the FBUs
1 FBU 1 2 FBU 2 or Dual microSD 64GB
Enterprise
Preliminary steps
▶
"Shutting down the server" on page 45.
▶
"Disconnecting the power cord" on page 46.
Expansion cards and backup units
RX2520 M5 Upgrade and Maintenance Manual 247
