If applicable, connect the OOB cable to connector "X11" on the backplane
(3).
For the cable plan see "Appendix B" on page 463
.
Concluding steps
▶
If applicable "Installing the CPU and heat sink" on page 288
.
▶
"Installing the fan holder" on page 61.
▶
"Installing the air duct" on page 59.
▶
Install HDD modules or HDD dummy modules into all HDD bays, see
"Installing a 3.5-inch HDD module" on page 134 and "Installing a 3.5-inch
dummy module" on page 136.
For more information on HDD mounting order, see "Overview of
configurations" on page 130.
▶
"Reassembling" on page 51.
▶
"Connecting the power cord" on page
56.
▶
"Switching on the server" on page 57.
▶
"Resuming BitLocker functionality" on page 88.
7.4.8 Replacing the SAS expander board
Field Replaceable Unit
(FRU)
Hardware: 10 minutes
Tools:
– Phillips PZ2 / (+) No. 2 screw driver
–
Hexagon screw driver 5 mm (not valid for Japan)
Preliminary steps
▶
"Locating the defective server" on page 43
.
▶
"Suspending BitLocker functionality" on page 65.
Hard disk drive (HDD) / solid state disk (SSD)
RX2520 M5 Upgrade and Maintenance Manual 157
