Install the Dual microSD 64GB Enterprise, see "Installing the Dual microSD
64GB Enterprise" on page 413
.
Concluding steps
▶
"Reassembling" on page 51.
▶
"Connecting the power cord" on page 56.
▶
"Switching on the server" on page 57.
15.8 System board
15.8.1 Replacing the system board
Field Replaceable Unit
(FRU)
Hardware: 50 minutes
Software: 10 minutes
Tools: Replacing the system board:
–
Phillips PH2 / (+) No. 2 screw driver
–
Magnifying glass for inspecting CPU socket springs
(recommended)
Replacing the TPM:
– Bit screw driver
–
TPM bit insert
(*)
–
thin slotted screw driver (2 x 0.4 mm)
(*)
(*)
For Japan:
– Dedicated TPM screw driver (CWZ8291A)
– TPM module fixing tool (S26361-F3552-L909)
System board and components
RX2520 M5 Upgrade and Maintenance Manual 423
