Match the two screw holes of the connector card with the holes in the SAS
expander board holder.
▶
Fasten the mounted SAS expander board with two screws on the SAS
expander board holder (see circles).
▶
Install the SAS expander board holder
, see "Installing the SAS expander
board holder" on page 155.
Concluding steps
▶
"Installing the fan holder" on page 61.
▶
"Installing the air duct" on page 59.
▶
"Reassembling" on page 51.
▶
"Connecting the power cord" on page 56.
▶
"Switching on the server" on page 57.
▶
"Resuming BitLocker functionality" on page 88.
7.4.9 Replacing the connector card
Field Replaceable Unit
(FRU)
Hardware: 10 minutes
Tools: Phillips PZ2 / (+) No. 2 screw driver / hexagon screw driver 5 mm
Preliminary steps
▶
"Locating the defective server" on page 43
.
▶
"Suspending BitLocker functionality" on page 65.
▶
"Shutting down the server" on page 45.
▶
"Disconnecting the power cord" on page 46.
▶
"Getting access to the component" on page 47.
▶
"Removing the air duct" on page 58.
Hard disk drive (HDD) / solid state disk (SSD)
162 Upgrade and Maintenance Manual RX2520 M5
