6.4.3 Replacing the power distribution board
Field Replaceable Unit
(FRU)
Hardware: 10 minutes
Tools: Phillips PH2 / (+) No. 2 screw driver
Preliminary steps
▶
"Locating the defective server" on page 43
.
▶
"Suspending BitLocker functionality" on page 65.
▶
"Shutting down the server" on page 45.
▶
"Disconnecting the power cord" on page 46.
▶
"Getting access to the component" on page 47.
▶
"Removing the air duct" on page 58.
▶
"Removing the crossbar" on page 62.
Removing the power distribution board
▶
Remove the PSU from bay 2, see "Removing the power distribution board"
on page 117
▶
Remove the power distribution board, see "Removing the power distribution
board" on page 117
Installing the power distribution board
▶
Install the power distribution board, see "Installing the power distribution
board" on page 113
▶
Install the PSU in bay 2, see "Installing a hot-plug PSU" on page 105
Concluding steps
▶
"Installing the crossbar" on page 63.
▶
"Installing the air duct" on page 59.
Power supply unit (PSU)
120 Upgrade and Maintenance Manual RX2520 M5
