Fujitsu PRIMERGY RX2520 M5

Figure 284: Front side 3.5-inch HDDs (up to 12 HDDs)
1 Bays for HDDs (depending on the
configuration)
2 Front panel on QRL
16.1.2 Server rear
Figure 285: Rear side
1 Up to 2 PSUs / dummy cover
2 PCI slots 9
3
PCI slots 8
4 I/O panel
5 PCI slot 4
6 PCI slot 3
7 PCI slot 2
8 PCI slot 1
Appendix A
