For more information on HDD mounting order, see "Overview of
configurations" on page 130.
▶
"Reassembling" on page 51.
▶
"Disconnecting the power cord" on page
46.
▶
"Switching on the server" on page 57.
7.4.6 Upgrading to 8x 3.5-inch HDD configuration
Upgrade and Repair Unit
(URU)
Hardware: 10 minutes
Software: 10 minutes
Tools: – Phillips PZ2 / (+) No. 2 screw driver
–
Hexagon screw driver 5 mm (not valid for Japan)
Preliminary steps
▶
"Suspending BitLocker functionality" on page 65
.
▶
"Shutting down the server" on page 45.
▶
"Disconnecting the power cord" on page 46.
▶
"Getting access to the component" on page 47.
▶
"Removing the air duct" on page 58.
▶
"Removing the fan holder" on page 60.
Installing the second 3.5-inch HDD backplane
▶
Install the second backplane, see "Installing a 3.5-inch HDD backplane" on
page 143.
▶
Connect the second backplane, see "Connecting a 3.5-inch HDD
backplane" on page 145.
▶
Connect the power cable from the second backplane to connector PWR2 on
the system board.
Hard disk drive (HDD) / solid state disk (SSD)
RX2520 M5 Upgrade and Maintenance Manual 147
