Regard that the air duct engages in the guiding points.
If there is a FBU installed, follow the procedure that is described in
"Installing an FBU" on page 247.
4.9
Handling the fan holder
4.9.1 Removing the fan holder
Figure 13: Removing the fan holder
▶
Disconnect all fan cables (see circles).
▶
Lift the fan holder out of the chassis.
Basic hardware procedures
60 Upgrade and Maintenance Manual RX2520 M5
