Page #139 background image
Removing the defective 3.5-inch HDD module
Remove the HDD module, see "Removing a 3.5-inch HDD module" on
page 136.
If applicable, remove the HDD from the installation frame, see "Handling
HDDs or SSDs without installation frame" on page 125.
Installing the new 3.5-inch HDD module
If applicable, install the HDD in the installation frame, see "Handling HDDs
or SSDs without installation frame" on page
125.
Install the HDD module, see "Installing a 3.5-inch HDD module" on
page 134.
Concluding steps
If the HDD is configured using a RAID controller with a RAID level higher
than "0", the rebuild will start automatically, see "Performing a RAID array
rebuild" on page 89.
7.4.5 Replacing the 3.5-inch HDD backplane
Your server can be equipped with up to two backplanes. The replacing
procedure is always the same.
Field Replaceable Unit
(FRU)
Hardware: 10 minutes
Tools:
Phillips PZ2 / (+) No. 2 screw driver
Hexagon screw driver 5 mm (not valid for Japan)
Preliminary steps
"Locating the defective server" on page 43
.
"Shutting down the server" on page 45.
"Disconnecting the power cord" on page 46.
Hard disk drive (HDD) / solid state disk (SSD)
RX2520 M5 Upgrade and Maintenance Manual 139
