Position
Logical
drive
number
ServerView RAID Manager display name
(Enclosure number: Port number)
one SAS controller
[0] 0 Vendor Product (0)
[1] 1 Vendor Product (1)
[2] 2 Vendor Product (2)
[3] 3 Vendor Product (3)
[4] 4 Vendor Product (4)
[5] 5 Vendor Product (5)
[6] 6 Vendor Product (6)
[7] 7 Vendor Product (7)
[8] 8 Vendor Product (8)
[9] 9 Vendor Product (9)
[10] 10 Vendor Product (10)
[11] 11 Vendor Product (11)
7.4.2 Installing 3.5-inch HDD modules
Customer Replaceable
Unit (CRU)
Hardware: 5 minutes
Tools: tool-less
Preliminary steps
▶
Locate the correct drive bay, see "Overview of configurations" on page
130.
Removing a 3.5-inch HDD dummy module
In configuration with only one 4x 3.5-inch HDD backplane dummy locks
are installed to make it impossible to equip the bays with no HDD
backplane behind.
Hard disk drive (HDD) / solid state disk (SSD)
132 Upgrade and Maintenance Manual RX2520 M5
