Fujitsu PRIMERGY RX2520 M5

▶
"Removing the fan holder" on page 60
.
Removing the SAS expander board holder
▶
Remove the assembled SAS expander board holder, see "Removing the
SAS expander board holder" on page 150.
Removing the defective connector card
Figure 77: Removing the connector card
▶
Remove the two screws (see circles).
▶
Disconnect the connector card from the SAS expander board.
Hard disk drive (HDD) / solid state disk (SSD)
RX2520 M5 Upgrade and Maintenance Manual 163
