Connecting a 4x 2.5-inch PCIe SSD backplane
▶
Connect the cables to the PCIe SSD backplane, see "Connecting the 4x
2.5-inch PCIe SSD backplane" on page 203
.
Concluding steps
▶
"Installing the fan holder" on page 61.
▶
"Installing the air duct" on page 59.
▶
"Reassembling" on page 51.
▶
Insert all PCIe SSD modules, see "Installing 2.5-inch PCIe SSD modules"
on page 179.
Make sure that you reinstall the PCIe SSD module in the bay it was
located before the PCIe SSD backplane replacement.
▶
"Connecting the power cord" on page 56.
▶
"Switching on the server" on page
57.
▶
"Resuming BitLocker functionality" on page 88.
Hard disk drive (HDD) / solid state disk (SSD)
208 Upgrade and Maintenance Manual RX2520 M5
