Preliminary steps
▶
"Suspending BitLocker functionality" on page 65
.
▶
"Shutting down the server" on page 45.
▶
"Disconnecting the power cord" on page 46.
▶
"Getting access to the component" on page 47.
▶
"Removing the air duct" on page 58.
▶
"Removing the fan holder" on page 60.
Installing the SAS expander board
Figure 101: Positioning the SAS expander board
▶
Position the SAS expander board on the SAS expander board holder. Notice
the recesses and hooks (see circles).
Hard disk drive (HDD) / solid state disk (SSD)
194 Upgrade and Maintenance Manual RX2520 M5
