Removing the SAS expander board holder
Figure 104: Removing the SAS expander board holder
▶
Disconnect all cables from the SAS expander board (see orange arrows).
▶
Remove the two screws (see circles).
▶
Push the SAS expander board holder towards and take it out of the chassis
(see blue arrow).
Hard disk drive (HDD) / solid state disk (SSD)
198 Upgrade and Maintenance Manual RX2520 M5
