Removing the ODD dummy cover
Figure 186: Removing the ODD dummy cover
▶
Unlock the dummy cover.
▶
Remove the dummy cover
.
CAUTION
▶
Keep the dummy cover for future use.
▶
If you remove the ODD again and do not replace it with a new
one, the dummy cover must be reinstalled to comply with EMC
regulations and to satisfy cooling requirements and fire
protection measures.
Accessible drives
RX2520 M5 Upgrade and Maintenance Manual 307
