Removing the air grid
Figure 198: Removing the air grid
▶
Remove the four screws (see circles).
Keep the four screws - they will be reused for fixing the LTO drive.
▶
Remove the air grid.
CAUTION
▶
Keep the air grid for future use.
▶
If you remove the accessible drive again and do not replace it
with a new one, the air grid must be reinstalled to comply with
EMC regulations and to satisfy cooling requirements and fire
protection measures.
Accessible drives
320 Upgrade and Maintenance Manual RX2520 M5
