Removing the front panel on QRL
The front panel on QRL and the front panel cable are combined in one
spare part.
Figure 237: Disconnecting the front panel cable
▶
Pull up the locking bar (1).
▶
Remove the front panel cable (2).
Front panel
RX2520 M5 Upgrade and Maintenance Manual 367
