Tools: Removing the system board:
– Phillips PH2 / (+) No. 2 screw driver/ hexagon screw driver 5 mm
Removing the TPM:
–
Bit screw driver
– flat nose pliers
–
TPM bit insert
(*)
(*)
For Japan:
– TPM module fixing tool (S26361-F3552-L909)
CAUTION
▶
Advise your contact persons that they must provide you with all
recovery keys which belong to the system to restore them in the
TPM later.
Preliminary steps
Preliminary steps are not necessary, if a system board has to be
replaced and the TPM is used again.
Before removing the TPM board, perform the following steps:
▶
Before removing the TPM board, remove the BitLocker protection and
decrypt the volume, see "Removing BitLocker protection and decrypting the
volume".
▶
Disable the TPM in the system board BIOS, see "Disabling the TPM in the
system board BIOS".
▶
"Suspending BitLocker functionality" on page
65.
▶
"Shutting down the server" on page
45.
▶
"Disconnecting the power cord" on page 46.
▶
"Getting access to the component" on page 47.
▶
"Removing the air duct" on page 58.
▶
"Removing the fan holder" on page 60.
System board and components
RX2520 M5 Upgrade and Maintenance Manual 395
