Exit the BIOS.
Resetting the boot retry counter using the ServerV
iew Operations
Manager
In the ServerV
iew Operations Manager Administration view, select Server
Configuration.
If more than one server is managed in SVOM, select the target server and
click Next.
From the Server Configuration menu pane, choose Restart Options.
Under Reboot Retries, specify the maximum number of boot attempts (0 to
7) in the Default for reboot tries field.
Resetting the boot retry counter using iRMC web interface
Enter the ServerView iRMC web interface.
Select the Server Management menu.
The following boot retry counter settings are available under ASR&R
Options:
Under Retry counter max specify the maximum number of attempts to
boot the OS (0 to 7).
Under Retry counter the current number of remaining boot attempts is
displayed. Overwrite this value with the maximum number of boot
attempts specified above in order to reset the boot retry counter.
Click Apply for the changes to take effect.
For more information on iRMC settings, see the iRMC user guides.
Basic software procedures
RX2520 M5 Upgrade and Maintenance Manual 77
