Page #99 background imageLoading...
Page #99 background image
Click Start Fan Test
.
For more information on iRMC settings, see the iRMC user guides.
Executing the fan test via ServerView Operations Manager
Open the ServerV
iew Operations Manager and log in.
Under
Administration select Server Configuration.
In the hierarchy tree of the Server list tab, select the server to be
configured.
In the right-hand side of the window, specify the details on the selected
server and confirm your entries by clicking GO.... In the left-hand section of
the window, the Configuration tab is being activated.
In the navigation area of the Configuration tab, select Other Settings.
Under Daily Fan Test, set the daily fan test time to a few minutes from the
current time. (Ensure to note down your previous setting.)
Click Save Page.
The fan test will be started at the specified time.
After the fan test is complete, restore the time setting to its initial value and
click Save Page.
In case of maintenance done by Fujitsu engineers in Japan:
Executing the fan test via Chassis ID Prom Tool
Please follow the instructions provided separately.
Basic software procedures
RX2520 M5 Upgrade and Maintenance Manual 99

Table of Contents

Other manuals for Fujitsu PRIMERGY RX2520 M5

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Fujitsu PRIMERGY RX2520 M5 and is the answer not in the manual?

Fujitsu PRIMERGY RX2520 M5 Specifications

General IconGeneral
Tcase72 °C
Scalability4S
Processor cache16.5 MB
Processor cores4
Processor model5222
System bus rate- GT/s
Processor socketLGA 3647 (Socket P)
Processor threads8
Processor codenameCascade Lake
Execute Disable BitYes
Motherboard chipsetIntel® C624
Processor frequency3.8 GHz
Processor cache typeL3
Processor lithography14 nm
Processor manufacturerIntel
Processor package size76.0 x 56.5 mm
Processor boost frequency3.9 GHz
Processor operating modes64-bit
Embedded options availableNo
Supported instruction setsAVX-512
Thermal Design Power (TDP)105 W
Number of processors installed1
Maximum number of SMP processors2
Maximum number of PCI Express lanes48
Memory types supported by processorDDR4-SDRAM
Memory clock speeds supported by processor2933 MHz
Maximum internal memory supported by processor1024 GB
HDD size- \
RAID levels0, 1
HDD interface-
Supported HDD sizes2.5 \
Total storage capacity0 GB
Maximum storage capacity- TB
Number of HDDs installed0
Chassis typeRack (2U)
Trusted Platform Module (TPM) version2.0
Compatible operating systemsMicrosoft Hyper-V Server 2016 Microsoft Windows Server 2016 Datacenter Microsoft Windows Server 2016 Standard Microsoft Windows Server 2016 Essentials Microsoft Windows Storage Server 2016 Standard Microsoft Hyper-V Server 2012 R2 Microsoft Windows Server 2012 R2 Datacenter Microsoft Windows Server 2012 R2 Standard Microsoft Windows Server 2012 R2 Essentials Microsoft Windows Storage Server 2012 R2 Standard VMware vSphere 6.5 VMware vSphere 6.0 SUSE Linux Enterprise Server 12 Red Hat Enterprise Linux 7 Red Hat Enterprise Linux 6 Univention Corporate Server 4
Memory slots12
Internal memory32 GB
Maximum internal memory768 GB
Cabling technology10/100/1000Base-T(X)
Ethernet interface typeGigabit Ethernet
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity6
Power supply800 W
Operating temperature (T-T)5 - 45 °C
Operating relative humidity (H-H)10 - 85 %
CertificationCB, RoHS, WEEE, GS, CE, CSAc/us, FCC Class A, ICES-003/NMB-003 Class A, VCCI:V3 Class A + JIS 61000-3-2, EAC, KC, CCC, RCM, BSMI
PCI Express slots version3.0
PCI Express x16 (Gen 3.x) slots3
On-board graphics card modelNot available
Processor ARK ID192445
Weight and Dimensions IconWeight and Dimensions
Depth770 mm
Width482.4 mm
Height86.6 mm
Weight25000 g
