3.30.2. Current threshold for activating Firing Change
Address
Format
GPC-OP
menu
Acronym
Global / M/E1/E2
GF_eXpress menu
Attribute Retentive Type Unit of mea- surement Default
Single-
node
Multi-
node
Description
1926
902 16 bit
09.04.02
FC.thr
M
MainMenu → M → Power controls →
FC.thr_1
R/W
■
Float
(####.#)
A 0.02950 09.05.01 E1
MainMenu → E1 → Power controls →
FC.thr_2
4998 09.06.01 E2
MainMenu → E2 → Power controls →
FC.thr_3
The parameter sets the current value required to activate the Firing Change (only with hd.7 = +256).
min...max: 0.0...3275.0
3.30.3. Current hysteresis for activating Firing Change
Address
Format
GPC-OP
menu
Acronym
Global / M/E1/E2
GF_eXpress menu
Attribute Retentive Type Unit of mea- surement Default
Single-
node
Multi-
node
Description
1920
896 16 bit
09.04.03
FC.tA
M
MainMenu → M → Power controls →
FC.tA_1
R/W
■
Float
(####.#)
% 10.02944 09.05.02 E1
MainMenu → E1 → Power controls →
FC.tA_2
4992 09.06.02 E2
MainMenu → E2 → Power controls →
FC.tA_3
The parameter sets the current hysteresis value required to activate the Firing Change. It is expressed in % of the current threshold Fu.tA
or FC.thr (only if enabled by setting hd.7 = +256).
min...max: 0.0...100.0
3.30.4. Minimum power for activating Firing Change
Address
Format
GPC-OP
menu
Acronym
Global / M/E1/E2
GF_eXpress menu
Attribute Retentive Type Unit of mea- surement Default
Single-
node
Multi-
node
Description
1924
900 16 bit
09.04.04
FC.P
M
MainMenu → M → Power controls →
FC.P_1
R/W
■
Float
(####.#)
% 0.02948 09.05.03 E1
MainMenu → E1 → Power controls →
FC.P_2
4996 09.06.03 E2
MainMenu → E2 → Power controls →
FC.P_3
This parameter sets the minimum power value required to activate the Firing Change.
min...max: 0.0...100.0
