gefran GPC - Maximum Temperature Value of SSR Heat Sink; Maximum Temperature Value of the Power Board

81901A “MSW_GPC-40/600A”_03-2021_ENG_page 79
3.16.5. Maximum temperature value of SSR heat sink
Address
Format
GPC-OP
menu
Acronym
Global / M/E1/E2
GF_eXpress menu
Attribute Retentive Type Unit of mea- surement Default
Single-
node
Multi-
node
Description
1352
328 16 bit
In.Ntc.
SSR.
Max1
M
MainMenu → M → Expert →
Status → In.Ntc.SSR.Max1_1
R
■
Float
(####.#)
°C2376 E1
MainMenu → E1 → Expert →
Status → In.Ntc.SSR.Max1_2
4424 E2
MainMenu → E2 → Expert →
Status → In.Ntc.SSR.Max1_3
1703
679 16 bit
In.Ntc.
SSR.
Max2
M
MainMenu → M → Expert →
Status → In.Ntc.SSR.Max2_1
R
■
Float
(####.#)
°C2727 E1
MainMenu → E1 → Expert →
Status → In.Ntc.SSR.Max2_2
4775 E2
MainMenu → E2 → Expert →
Status → In.Ntc.SSR.Max2_3
The parameter shows the maximum temperature shown by the SSR heatsink temperature sensor of GPC-M, GPC-E1 and GPC-E2.
The differences are:
• In.Ntc.SSR.Max1 shows the maximum temperature value since the last reset. To reset the parameter, see paragraph “3.16.8. Max1
temperature reset”.
• In.Ntc.SSR.Max2 shows the maximum temperature value over the entire lifetime of the device, i.e., since the first power-on. The
parameter cannot be reset.
3.16.6. Maximum temperature value of the power board
Address
Format
GPC-OP
menu
Acronym
Global / M/E1/E2
GF_eXpress menu
Attribute Retentive Type Unit of mea- surement Default
Single-
node
Multi-
node
Description
1387
363 16 bit
In.Ntc.
AIR.
Max1
M
MainMenu → M → Expert →
Status → In.Ntc.AIR.Max1_1
R
■
Float
(####.#)
°C2411 E1
MainMenu → E1 → Expert →
Status → In.Ntc.AIR.Max1_2
4459 E2
MainMenu → E2 → Expert →
Status → In.Ntc.AIR.Max1_3
1353
329 16 bit
In.Ntc.
AIR.
Max2
M
MainMenu → M → Expert →
Status → In.Ntc.AIR.Max2_1
R
■
Float
(####.#)
°C2377 E1
MainMenu → E1 → Expert →
Status → In.Ntc.AIR.Max2_2
4425 E2
MainMenu → E2 → Expert →
Status → In.Ntc.AIR.Max2_3
The parameter shows the maximum temperature of the power board shown by the air temperature sensor of GPC-M, GPC-E1 and
GPC-E2.
The differences are:
• In.Ntc.AIR.Max1 shows the maximum temperature value since the last reset
. To reset the parameter see paragraph “3.16.8. Max1
temperature reset”.
• In.Ntc.AIR.Max2 shows the maximum temperature value over the entire lifetime of the device, i.e., since its first power-on. The pa-
rameter cannot be reset.
