gefran GPC - Status Reset to Last Activation of Custom OUT9; Status Reset to Last Activation of Custom OUT10; Physical Output Status

81901 “MSW_GPC-40/600A”_03-2021_ENG_page 90
3.19.8. Status reset to last activation of custom OUT9
Address
Format
GPC-OP
menu
Acronym
Global / M/E1/E2
GF_eXpress menu
Attribute Retentive Type Unit of mea- surement Default
Single-
node
Multi-
node
Description
1134 110 bit
BIT_
RESET_
OUT9_
CUSTOM
Global
MainMenu → Global → Expert →
Bit → BIT_RESET_OUT9_CUSTOM
R/W
The bit resets the status to the last activation of custom output 9.
Options: OFF = No action
ON = Resets the status to the last activation of custom OUT9
3.19.9. Status reset to last activation of custom OUT10
Address
Format
GPC-OP
menu
Acronym
Global / M/E1/E2
GF_eXpress menu
Attribute Retentive Type Unit of mea- surement Default
Single-
node
Multi-
node
Description
1135 111 bit
BIT_
RESET_
OUT10_
CUSTOM
Global
MainMenu → Global → Expert →
Bit → BIT_RESET_OUT10_CUSTOM
R/W
The bit resets the status to the last activation of custom output 10.
Options: OFF = No action
ON = Resets the status to the last activation of custom OUT10
3.19.10. Physical output status
Address
Format
GPC-OP
menu
Acronym
Global / M/E1/E2
GF_eXpress menu
Attribute Retentive Type Unit of mea- surement Default
Single-
node
Multi-
node
Description
1106 82 bit
BIT_
STATUS_
OUT1
Global
MainMenu → Global → Expert →
Bit → BIT_STATUS_OUT1
R
1107 83 bit
BIT_
STATUS_
OUT2
Global
MainMenu → Global → Expert →
Bit → BIT_STATUS_OUT2
R
1108 84 bit
BIT_
STATUS_
OUT3
Global
MainMenu → Global → Expert →
Bit → BIT_STATUS_OUT3
R
1110 86 bit
BIT_
STATUS_
OUT5
Global
MainMenu → Global → Expert →
Bit → BIT_STATUS_OUT5
R
1111 87 bit
BIT_
STATUS_
OUT6
Global
MainMenu → Global → Expert →
Bit → BIT_STATUS_OUT6
R
1112 88 bit
BIT_
STATUS_
OUT7
Global
MainMenu → Global → Expert →
Bit → BIT_STATUS_OUT7
R
1113 89 bit
BIT_
STATUS_
OUT8
Global
MainMenu → Global → Expert →
Bit → BIT_STATUS_OUT8
R
1114 90 bit
BIT_
STATUS_
OUT9
Global
MainMenu → Global → Expert →
Bit → BIT_STATUS_OUT9
R
1115 91 bit
BIT_
STATUS_
OUT10
Global
MainMenu → Global → Expert →
Bit → BIT_STATUS_OUT10
R
The bits show the status of the physical outputs.
Options: OFF = Output off
ON = Output on
