81901A “MSW_GPC-40/600A”_03-2021_ENG_page 127
3.35.5. Fieldbus board firmware version
Address
Format
GPC-OP
menu
Acronym
Global /
M/E1/E2
GF_eXpress menu
Attribute
Retentive
Type
Unit of mea-
surement
Default
Single-
node
Multi-
node
Description
1717 693 16 bit 02.10 UPd.F Global
MainMenu → Global → Info → UPd.F
R
Float
(###.##)
The log shows the firmware version of the Fieldbus board.
3.35.6. Fieldbus board node
Address
Format
GPC-OP
menu
Acronym
Global /
M/E1/E2
GF_eXpress menu
Attribute
Retentive
Type
Unit of mea-
surement
Default
Single-
node
Multi-
node
Description
1719 695 16 bit 02.11 Cod.F Global
MainMenu → Global → Info → Cod.F
R
Unsigned
Short
The register shows the node number of the Fieldbus board.
3.35.7. Fieldbus board baudrate
Address
Format
GPC-OP
menu
Acronym
Global /
M/E1/E2
GF_eXpress menu
Attribute
Retentive
Type
Unit of mea-
surement
Default
Single-
node
Multi-
node
Description
1720 696 16 bit 02.12 bAu.F Global
MainMenu → Global → Comms → bAu.F
R
Unsigned
Short
The register shows the transmission speed of the Fieldbus board, based on the Fieldbus type.
Options:
Profibus CANopen Ethernet
bAu.f baudrate bAu.f baudrate bAu.f baudrate
0 12.00 Mbit/s 0 1000 kbit/s 0 100 Mbit/s
1 6.00 Mbit/s 1 800 kbit/s 1 10 Mbit/s
2 3.00 Mbit/s 2 500 kbit/s
3 1.50 Mbit/s 3 250 kbit/s
4 500.00 kbit/s 4 125 kbit/s
5 187.50 kbit/s 5 100 kbit/s
6 93.75 kbit/s 6 50 kbit/s
7 45.45 kbit/s 7 20 kbit/s
8 19.20 kbit/s 8 10 kbit/s
9 9.60 kbit/s
3.35.8. I/O data size for Fieldbus
Address
Format
GPC-OP
menu
Acronym
Global /
M/E1/E2
GF_eXpress menu
Attribute
Retentive
Type
Unit of mea-
surement
Default
Single-
node
Multi-
node
Description
1918 894 16 bit 03.01.05 F.SIZE Global
MainMenu → Global → Comms → F.SIZE
R/W
■
Unsigned
Short
0
This parameter sets the I/O data size for the Fieldbus.
Options: 0 = 12 WORD per input + 12 WORD per output
1 = 24 WORD per input + 24 WORD per output
