3.35.19. Status (STATUS)
Address
Format
GPC-OP
menu
Acronym
Global / M/E1/E2
GF_eXpress menu
Attribute Retentive Type Unit of mea- surement Default
Single-
node
Multi-
node
Description
1491
467 16 bit
01.02.15
STATUS
M
MainMenu → M → Status → STATUS_1
R
Unsigned
Short
2515 01.03.15 E1
MainMenu → E1 → Status → STATUS_2
4563 01.04.15 E2
MainMenu → E2 → Status → STATUS_3
The parameter shows the status of the device. The individual statuses are highlighted by the corresponding bit.
Options:
bit State of
0
AL1 OR AL2 OR AL3 OR AL4 or AL.HB (OR PHASES
1/2/3 with three-phase load) OR POWER_FAULT
5 Ou.P > 0
8 AL1
9 AL2
10 AL3
11 AL4
12 AL.HB OR POWER_FAULT
13 ON/OFF
14 AUTO/MAN
3.35.20. Status 1 (STATUS1)
Address
Format
GPC-OP
menu
Acronym
Global / M/E1/E2
GF_eXpress menu
Attribute Retentive Type Unit of mea- surement Default
Single-
node
Multi-
node
Description
1493
469 16 bit
01.02.16
STATUS1
M
MainMenu → M → Status → STATUS1_1
R
Unsigned
Short
2517 01.03.16 E1
MainMenu → E1 → Status → STATUS1_2
4565 01.04.16 E2
MainMenu → E2 → Status → STATUS1_3
The parameter shows the status of the device. The individual statuses are highlighted by the corresponding bit.
Options:
bit State of
0
AL1 OR AL2 OR AL3 OR AL4 or AL.HB (OR PHASES
1/2/3 with three-phase load) OR POWER_FAULT
8 AL1
9 AL2
10 AL3
11 AL4
12 AL.HB PHASE 1 (with three-phase load)
13 AL.HB PHASE 2 (with three-phase load)
14 AL.HB PHASE 3 (with three-phase load)
