3.13.4. Alarm hysteresis
Address
Format
GPC-OP
menu
Acronym
Global / M/E1/E2
GF_eXpress menu
Attribute Retentive Type Unit of mea- surement Default
Single-
node
Multi-
node
Description
1211
187 16 bit
05.01.26
Hy.1
M
MainMenu → M → Alarms →
AL1...AL8 alarms → AL1 → Hy.1_1
R/W
■
Float *
s.p. *
sec.
min.
12235 05.02.26 E1
MainMenu → E1 → Alarms →
AL1...AL8 alarms → AL1 → Hy.1_2
4283 05.03.26 E2
MainMenu → E2 → Alarms →
AL1...AL8 alarms → AL1 → Hy.1_3
1212
188 16 bit
05.01.27
Hy.2
M
MainMenu → M → Alarms →
AL1...AL8 alarms → AL2 → Hy.2_1
R/W
■
Float *
s.p. *
sec.
min.
12236 05.02.27 E1
MainMenu → E1 → Alarms →
AL1...AL8 alarms → AL2 → Hy.2_2
4284 05.03.27 E2
MainMenu → E2 → Alarms →
AL1...AL8 alarms → AL2 → Hy.2_3
1213
189 16 bit
05.01.28
Hy.3
M
MainMenu → M → Alarms →
AL1...AL8 alarms → AL3 → Hy.3_1
R/W
■
Float *
s.p. *
sec.
min.
22237 05.02.28 E1
MainMenu → E1 → Alarms →
AL1...AL8 alarms → AL3 → Hy.3_2
4285 05.03.28 E2
MainMenu → E2 → Alarms →
AL1...AL8 alarms → AL3 → Hy.3_3
1083
59 16 bit
05.01.29
Hy.4
M
MainMenu → M → Alarms →
AL1...AL8 alarms → AL4 → Hy.4_1
R/W
■
Float *
s.p. *
sec.
min.
12107 05.02.29 E1
MainMenu → E1 → Alarms →
AL1...AL8 alarms → AL4 → Hy.4_2
4155 05.03.29 E2
MainMenu → E2 → Alarms →
AL1...AL8 alarms → AL4 → Hy.4_3
1234
210 16 bit
05.01.30
Hy.5
M
MainMenu → M → Alarms →
AL1...AL8 alarms → AL5 → Hy.5_1
R/W
■
Float *
s.p. *
sec.
min.
12258 05.02.30 E1
MainMenu → E1 → Alarms →
AL1...AL8 alarms → AL5 → Hy.1_2
4306 05.03.30 E2
MainMenu → E2 → Alarms →
AL1...AL8 alarms → AL5 → Hy.5_3
1235
211 16 bit
05.01.31
Hy.6
M
MainMenu → M → Alarms →
AL1...AL8 alarms → AL6 → Hy.6_1
R/W
■
Float *
s.p. *
sec.
min.
12259 05.02.31 E1
MainMenu → E1 → Alarms →
AL1...AL8 alarms → AL6 → Hy.6_2
4307 05.03.31 E2
MainMenu → E2 → Alarms →
AL1...AL8 alarms → AL6 → Hy.6_3
1236
212 16 bit
05.01.32
Hy.7
M
MainMenu → M → Alarms →
AL1...AL8 alarms → AL7 → Hy.7_1
R/W
■
Float *
s.p. *
sec.
min.
12260 05.02.32 E1
MainMenu →
E1 → Alarms →
AL1...AL8 alarms → AL7 → Hy.7_2
4308 05.03.32 E2
MainMenu → E2 → Alarms →
AL1...AL8 alarms → AL7 → Hy.7_3
1237
213 16 bit
05.01.33
Hy.8
M
MainMenu → M → Alarms →
AL1...AL8 alarms → AL8 → Hy.8_1
R/W
■
Float *
s.p. *
sec.
min.
12261 05.02.33 E1
MainMenu → E1 → Alarms →
AL1...AL8 alarms → AL8 → Hy.8_2
4309 05.03.33 E2
MainMenu → E2 → Alarms →
AL1...AL8 alarms → AL8 → Hy.8_3
The parameter sets the hysteresis for generic alarms AL1...AL8 of modules GPC-M, GPC-E1 and GPC-E2. The alarm and module con-
cerned depend on the address used.
*) The range of valid values for the threshold and the position of the decimal point may vary according to the reference variable chosen for
the alarm Ax.r (with x = 1...8).
min...max: -99.9...99.9 If symmetrical alarm
0...999With unit of measurement in seconds, if +32 in parameter Ax.t, with x = alarm number
0...999 With unit of measurement in minutes, if +64 in parameter Ax.t, with x = alarm number
For further information on symmetrical alarms, see paragraph “4.4.1. Generic alarms AL1...AL8”.
