3.19.13. STATUS4 stored with custom output activation
Address
Format
GPC-OP
menu
Acronym
Global / M/E1/E2
GF_eXpress menu
Attribute Retentive Type Unit of mea- surement Default
Single-
node
Multi-
node
Description
1323
299 16 bit
STATUS4_
FOR_
OUT09
M
MainMenu → Global → Expert → Output
Custom → STATUS4_FOR_OUT09_1
R
Unsigned
Short
2347 E1
MainMenu → Global → Expert → Output
Custom → STATUS4_FOR_OUT09_2
4395 E2
MainMenu → Global → Expert → Output
Custom → STATUS4_FOR_OUT09_3
1324
300 16 bit
STATUS4_
FOR_
OUT10
M
MainMenu → Global → Expert → Output
Custom → STATUS4_FOR_OUT10_1
R
Unsigned
Short
2348 E1
MainMenu → Global → Expert → Output
Custom → STATUS4_FOR_OUT10_2
4396 E2
MainMenu → Global → Expert → Output
Custom → STATUS4_FOR_OUT10_3
The parameter shows the STATUS4 status stored at the last activation of custom outputs OUT9 and OUT10.
3.19.14. ALSTATE_IRQ stored with custom output activation
Address
Format
GPC-OP
menu
Acronym
Global / M/E1/E2
GF_eXpress menu
Attribute Retentive Type Unit of mea- surement Default
Single-
node
Multi-
node
Description
1356
332 16 bit
ALSTATE_
IRQ_FOR_
OUT09
M
MainMenu → Global → Expert → Output
Custom → ALSTATE_IRQ_FOR_OUT09_1
R
Unsigned
Short
2380 E1
MainMenu → Global → Expert → Output
Custom → ALSTATE_IRQ_FOR_OUT09_2
4428 E2
MainMenu → Global → Expert → Output
Custom → ALSTATE_IRQ_FOR_OUT09_3
1357
333 16 bit
ALSTATE_
IRQ_FOR_
OUT10
M
MainMenu → Global → Expert → Output
Custom → ALSTATE_IRQ_FOR_OUT10_1
R
Unsigned
Short
2381 E1
MainMenu → Global → Expert → Output
Custom → ALSTATE_IRQ_FOR_OUT10_2
4429 E2
MainMenu → Global → Expert → Output
Custom → ALSTATE_IRQ_FOR_OUT10_3
The parameter shows the ALSTATE_IRQ status stored at the last activation of custom outputs OUT9 and OUT10.
3.19.15. VOLTAGE_STATUS stored with custom output activation
Address
Format
GPC-OP
menu
Acronym
Global / M/E1/E2
GF_eXpress menu
Attribute Retentive Type Unit of mea- surement Default
Single-
node
Multi-
node
Description
1325 301 16 bit
VOLT-
AGE_
STATUS_
FOR_
OUT09
Global
MainMenu → Global →
Expert → Output Custom →
VOLTAGE_STATUS_FOR_OUT09
R
Unsigned
Short
1326 302 16 bit
VOLT-
AGE_
STATUS_
FOR_
OUT1
0
Global
MainMenu → Global →
Expert → Output Custom →
VOLTAGE_STATUS_FOR_OUT10
R
Unsigned
Short
The parameter shows the VOLTAGE_STATUS stored at the last activation of custom outputs OUT9 and OUT10.
