3.35.16. O1 - O2 - O3 LED function
Address
Format
GPC-OP
menu
Acronym
Global / M/E1/E2
GF_eXpress menu
Attribute Retentive Type Unit of mea- surement Default
Single-
node
Multi-
node
Description
1646 622 16 bit 06.08.05 Ld.5 Global
MainMenu → Global → Leds → Ld.5
R/W
■
Unsigned
Short
1
1647 623 16 bit 06.08.06 Ld.6 Global
MainMenu → Global → Leds → Ld.6
R/W
■
Unsigned
Short
2
1648 624 16 bit 06.08.07 Ld.7 Global
MainMenu → Global → Leds → Ld.7
R/W
■
Unsigned
Short
3
1649 625 16 bit 06.08.08 Ld.8 Global
MainMenu → Global → Leds → Ld.8
R/W
■
Unsigned
Short
4
This parameter sets the function associated with the O1 (Ld.5), O2 (Ld.6), O3 (Ld.7) and BUTTON (Ld.8) LEDs, according to the address
used. The function is identified by an index.
Options:
Index Function associated with the LED
0 Disabled
1 Repetition of status OUT 1
2 Repetition of status OUT 2
3 Repetition of status OUT 3
4 Key status
5 Repetition of status OUT 5
6 Repetition of status OUT 6
7 Repetition of status OUT 7
8 Repetition of status OUT 8
9 Repetition of status OUT 9
10 Repetition of status OUT 10
12 Serial dialogue 1
13 Serial dialogue 2
14 INDIG3 digital input configuration
15 INDIG4 digital input configuration
By increasing the index by +16, the LED flashes if active.
3.35.17. Status (STATUS_W)
For STATUS_W, see paragraph “3.22.3. Status (STATUS_W)”.
3.35.18. Alarm status reading
To read the status of ALSTATE_IRQ alarms, see paragraph “3.13.14. Alarm status (ALSTATE_IRQ)”.
