3.31.1. Enabling feedback mode
Address
Format
GPC-OP
menu
Acronym
Global / M/E1/E2
GF_eXpress menu
Attribute Retentive Type Unit of mea- surement Default
Single-
node
Multi-
node
Description
1732
708 16 bit
09.01.10
hd.6
M
MainMenu → M → Power controls →
hd.6_1
R/W
■
Unsigned
Short
02756 09.02.10 E1
MainMenu → E1 → Power controls →
hd.6_2
4804 09.03.10 E2
MainMenu → E2 → Power controls →
hd.6_3
The parameter sets enabling of the feedback mode. The enabled mode is identified by an index.
Options:
Index Feedback mode
0 No feedback enabled
1 V
2
(quadratic voltage feedback)
2 I
2
(quadratic current feedback)
3 P (power feedback)
4 No feedback enabled
5 V (linear voltage feedback)
6 I (linear current feedback)
3.31.2. Maximum voltage feedback correction
Address
Format
GPC-OP
menu
Acronym
Global / M/E1/E2
GF_eXpress menu
Attribute Retentive Type Unit of mea- surement Default
Single-
node
Multi-
node
Description
1755
731 16 bit
09.01.11
Cor.V
M
MainMenu → M → Power controls →
Cor.V_1
R/W
■
Float
(####.#)
% 100.02779 09.02.11 E1
MainMenu → E1 → Power controls →
Cor.V_2
4827 09.03.11 E2
MainMenu → E2 → Power controls →
Cor.V_3
The parameter sets the maximum correction of the voltage feedback. It serves to limit the correction.
min...max: 0.0...100.0
3.31.3. Maximum current feedback correction
Address
Format
GPC-OP
menu
Acronym
Global / M/E1/E2
GF_eXpress menu
Attribute Retentive Type Unit of mea- surement Default
Single-
node
Multi-
node
Description
1756
732 16 bit
09.01.12
Cor.I
M
MainMenu → M → Power controls →
Cor.I_1
R/W
■
Float
(####.#)
% 100.02780 09.02.12 E1
MainMenu → M → Power controls →
Cor.I_2
4828 09.03.12 E2
MainMenu → M → Power controls →
Cor.I_3
The parameter sets the maximum correction of the current feedback. It serves to limit the correction.
min...max: 0.0...100.0
