gefran GPC - Status Reading (STATUS4); Max1 Temperature Reset

81901 “MSW_GPC-40/600A”_03-2021_ENG_page 80
3.16.7. Status reading (STATUS4)
Address
Format
GPC-OP
menu
Acronym
Global / M/E1/E2
GF_eXpress menu
Attribute Retentive Type Unit of mea- surement Default
Single-
node
Multi-
node
Description
1658
634 16 bit
01.02.19
STA-
TUS4
M
MainMenu → M →
Status → STATUS4_1
R
Unsigned
Short
2682 01.03.19 E1
MainMenu → E1 →
Status → STATUS4_2
4730 01.04.19 E2
MainMenu → E2 →
Status → STATUS4_3
The parameter shows the status of the device. The OFF bit indicates off, the ON bit indicates on.
Options:
bit Status
0 Faulty temperature sensor (TEMPERATURE_SENSOR_BROKEN)
1 Overtemperature (OVER_HEAT)
2 Active phase softstart
3 End of phase softstart
4 Frequency alarm or single-phase line failure alarm
5 60 Hz
6 Short-circuit current in phase softstart (SHORT_CIRCUIT_CURRENT)
7 Peak current limiter in phase softstart
8 RMS steady state current limiter
9 24 V fan power failure (SSR_SAFETY)
10 Fuse open (FUSE_OPEN)
11 Current polarity control
12 HSC current overload limiter in phase softstart
13 Faulty current transformer sensor
14 SSR hardware overtemperature (HW_OVER_HEAT)
3.16.8. Max1 temperature reset
Address
Format
GPC-OP
menu
Acronym
Global / M/E1/E2
GF_eXpress menu
Attribute Retentive Type Unit of mea- surement Default
Single-
node
Multi-
node
Description
1146
122 bit
RESET_
INNTC_
MAX1
M
MainMenu → M → Expert →
Bit → BIT_RESET_INNTC_MAX1_1
R/W2170 E1
MainMenu → E1 → Expert →
Bit → BIT_RESET_INNTC_MAX1_2
4218 E2
MainMenu → E2 → Expert →
Bit → BIT_RESET_INNTC_MAX1_3
The parameter resets the In.Ntc.SSR.Max1 and In.Ntc.AIR.Max1 temperatures.
Options: OFF = No action
ON = Reset of In.Ntc.SSR.Max1 and In.Ntc.AIR.Max1 temperatures
