81901 “MSW_GPC-40/600A”_03-2021_ENG_page 110
3.28.3. Minimum non-conduction time for ramp reactivation
Address
Format
GPC-OP
menu
Acronym
Global / M/E1/E2
GF_eXpress menu
Attribute Retentive Type Unit of mea- surement Default
Single-
node
Multi-
node
Description
1653
629 16 bit
09.01.06
PS.oF
M
MainMenu → M → Power controls →
PS.oF_1
R/W
■
Unsigned
Short
sec. 22677 09.02.06 E1
MainMenu → E1 → Power controls →
PS.oF_2
4725 09.03.06 E2
MainMenu → E2 → Power controls →
PS.oF_3
The parameter sets the minimum non-conduction time to reactivate the phase softstart ramp.
min...max: 0...999
3.28.4. Maximum peak current limit during ramp
Address
Format
GPC-OP
menu
Acronym
Global / M/E1/E2
GF_eXpress menu
Attribute Retentive Type Unit of mea- surement Default
Single-
node
Multi-
node
Description
1730
706 16 bit
09.01.06
PS.tA
M
MainMenu → M → Power controls →
PS.tA_1
R/W
■
Float
(####.#)
Apk
see
table
2754 09.02.06 E1
MainMenu → E1 → Power controls →
PS.tA_2
4802 09.03.06 E2
MainMenu → E2 → Power controls →
PS.tA_3
The parameter sets the maximum peak current limit during the phase softstart ramp.
The default value depends on the size of the controller:
Size
GPC-M, GPC-E1, GPC-E2
Default
40 A 110.0
60 A 170.0
100 A 280.0
150 A 420.0
200 A 560.0
250 A 700.0
300 A 840.0
400 A 1130.0
500 A 1410.0
600 A 1690.0
With a three-phase load, a different PS.tA parameter value can be set for each module.
This allows, for example, control of an
unbalanced three-phase load.
min...max: 0.0...3275.0
