gefran GPC - SSR Heat Sink Temperature Value; Temperature Value of LINE Terminals; Temperature Value of LOAD Terminals; Temperature Value of the Power Board

81901 “MSW_GPC-40/600A”_03-2021_ENG_page 78
3.16.1. SSR heat sink temperature value
Address
Format
GPC-OP
menu
Acronym
Global / M/E1/E2
GF_eXpress menu
Attribute Retentive Type Unit of mea- surement Default
Single-
node
Multi-
node
Description
1679
655 16 bit
In.Ntc.
SSR
M
MainMenu → M → Expert →
Status → In.Ntc.SSR_1
R
Float
(####.#)
°C2703 E1
MainMenu → E1 → Expert →
Status → In.Ntc.SSR_2
4751 E2
MainMenu → E2 → Expert →
Status → In.Ntc.SSR_3
The parameter shows the temperature recorded by the power module’s internal temperature sensor.
3.16.2. Temperature value of LINE terminals
Address
Format
GPC-OP
menu
Acronym
Global / M/E1/E2
GF_eXpress menu
Attribute Retentive Type Unit of mea- surement Default
Single-
node
Multi-
node
Description
1558
534 16 bit
In.Ntc.
LINE
M
MainMenu → M → Expert →
Status → In.Ntc.LINE_1
R
Float
(####.#)
°C2582 E1
MainMenu → E1 → Expert →
Status → In.Ntc.LINE_2
4630 E2
MainMenu → E2 → Expert →
Status → In.Ntc.LINE_3
The parameter shows the temperature recorded by the temperature sensor connected to the LINE terminals.
3.16.3. Temperature value of LOAD terminals
Address
Format
GPC-OP
menu
Acronym
Global / M/E1/E2
GF_eXpress menu
Attribute Retentive Type Unit of mea- surement Default
Single-
node
Multi-
node
Description
1559
535 16 bit
In.Ntc.
LOAD
M
MainMenu → M → Expert →
Status → In.Ntc.LOAD_1
R
Float
(####.#)
°C2583 E1
MainMenu → E1 → Expert →
Status → In.Ntc.LOAD_2
4631 E2
MainMenu → E2 → Expert →
Status → In.Ntc.LOAD_3
The parameter shows the temperature recorded by the temperature sensor connected to the LOAD terminals.
3.16.4. Temperature value of the power board
Address
Format
GPC-OP
menu
Acronym
Global / M/E1/E2
GF_eXpress menu
Attribute Retentive Type Unit of mea- surement Default
Single-
node
Multi-
node
Description
1560
536 16 bit
In.Ntc.
AIR
M
MainMenu → M → Expert →
Status → In.Ntc.AIR_1
R
Float
(####.#)
°C2584 E1
MainMenu → E1 → Expert →
Status → In.Ntc.AIR_2
4632 E2
MainMenu → E2 → Expert →
Status → In.Ntc.AIR_3
The parameter shows the temperature of the power board measured by the sensor in the air.
