3.35.11. Virtual DIP switch status
Address
Format
GPC-OP
menu
Acronym
Global / M/E1/E2
GF_eXpress menu
Attribute Retentive Type Unit of mea- surement Default
Single-
node
Multi-
node
Description
1798 774 16 bit 03.01.07 J.Ser Global
MainMenu → Global → Parameters →
J.Ser
R/W
■
Unsigned
Short
0
The parameter sets the configuration of the virtual DIP switches. For the values, see the jumper / DIP switch status tables in paragraph
“3.35.9. Jumper / DIP switch status”.
3.35.12. Manufacturer identification
Address
Format
GPC-OP
menu
Acronym
Global / M/E1/E2
GF_eXpress menu
Attribute Retentive Type Unit of mea- surement Default
Single-
node
Multi-
node
Description
1370 120 16 bit Global R
Unsigned
Short
5000
The log shows the name of the manufacturer (Gefran).
3.35.13. Product identification
Address
Format
GPC-OP
menu
Acronym
Global / M/E1/E2
GF_eXpress menu
Attribute Retentive Type Unit of mea- surement Default
Single-
node
Multi-
node
Description
1371 121 16 bit deviceID Global
MainMenu → Global → Info → deviceID
R
Unsigned
Short
218
The register shows the device identifier (GPC) within the Modbus communication network.
3.35.14. LED operation
The status of the LEDs RN, ER, DI1, DI2, O1, O2, O3 and BUT refers to the status of the corresponding parameter, with the following
exceptions:
LED behaviour Description of signal
LED RN (green) on Key function active
LED RN (green) and LED ER (red) flash quickly together Autobaud in progress
LED ER (red) flashing
Temperature alarm (OVER_HEAT OR TEMPERATURE_SEN-
SOR_BROKEN)
or
SHORT_CIRCUIT_CURRENT OR SSR_SAFETY OR HW_
OVER_HEAT OR FUSE_OPEN alarm (only for single-phase
configuration)
or
Interlock
LED ER (red) and LED Ox (yellow) both flashing HB alarm or POWER_FAULT of module x
All LEDs flashing rapidly except LED DI1 Jumper configuration not provided (MODE_ERROR)
All LEDs flashing rapidly except LED DI2
30%_UNBALANCED_ERROR alarm (only for three-phase
configuration)
All LEDs flashing rapidly except LED O1
SHORT_CIRCUIT_CURRENT alarm (only for three-phase
configuration)
All LEDs flashing rapidly except LED O2
TRIPHASE_MISSING_LINE_ERROR alarm (only for three-
phase configuration)
All LEDs flashing rapidly except LED O3
SSR_SAFETY OR HW_OVER_HEAT alarm (only for three-
phase configuration)
All LEDs flashing rapidly, except for the BUT LED. FUSE_OPEN alarm (only for three-phase configuration)
