81901A “MSW_GPC-40/600A”_03-2021_ENG_page 119
3.31.8. Feedback response speed
Address
Format
GPC-OP
menu
Acronym
Global /
M/E1/E2
GF_eXpress menu
Attribute
Retentive
Type
Unit of mea-
surement
Default
Single-
node
Multi-
node
Description
1765
741 16 bit
09.01.17
Fb.lt
M
MainMenu → M → Power controls →
Fb.lt_1
R/W
■
Float
(####.#)
% /
60 ms
0.32813 09.02.17 E1
MainMenu → E1 → Power controls →
Fb.lt_2
4837 09.03.17 E2
MainMenu → E2 → Power controls →
Fb.lt_3
The parameter sets the feedback response speed. The speed is expressed as a percentage change in output power calculated every 60
ms.
min...max: 0.1...5.0
3.31.9. Feedback reference calibration
Address
Format
GPC-OP
menu
Acronym
Global /
M/E1/E2
GF_eXpress menu
Attribute
Retentive
Type
Unit of mea-
surement
Default
Single-
node
Multi-
node
Description
1137
113 bit
12.01.06
BIT_
CALIB_
FEED-
BACK
M
MainMenu → M → Expert → Bit →
BIT_CALIB_FEEDBACK_1
R/W OFF2161 12.02.06 E1
MainMenu → E1 → Expert → Bit →
BIT_CALIB_FEEDBACK_2
4227 12.03.06 E2
MainMenu → E2 → Expert → Bit →
BIT_CALIB_FEEDBACK_3
The bit enables and disables calibration of the feedback reference.
Options: OFF = No function
ON = Calibration enabled
3.31.10. Feedback reference
Address
Format
GPC-OP
menu
Acronym
Global /
M/E1/E2
GF_eXpress menu
Attribute
Retentive
Type
Unit of mea-
surement
Default
Single-
node
Multi-
node
Description
1910
886 32 bit AriF
M
MainMenu → M → Expert →
Status → AriF_1
R
Float32
(see
table)
see
table
see
table
2934 E1
MainMenu → E1 → Expert →
Status → AriF_1
4982 E2
MainMenu → E2 → Expert →
Status → AriF_1
The parameter shows the feedback reference. The data is in DWord format (32 bit).
The LSW data in Word format (16 bit) is available at address 757 (1781 - 2805 - 4853).
The default value is the threshold of V, I, P to be maintained on the load.
Type of feedback
Voltage Current Power
Unit of measure-
ment
V A kW
Range 0.0...999.9 0.0...3275.0 0.00...1500.00
Format (####.#) (####.#) (###.##)
