3.14.6. HB alarm threshold percentage
Address
Format
GPC-OP
menu
Acronym
Global / M/E1/E2
GF_eXpress menu
Attribute Retentive Type Unit of mea- surement Default
Single-
node
Multi-
node
Description
1761
737 16 bit
05.04.04
Hb.P
M
MainMenu → M → Alarms →
HB alarm → Hb.P_1
R/W
■
Float
(####.#)
% 80.02785 05.05.04 E1
MainMenu → E1 → Alarms →
HB alarm → Hb.P_2
4833 05.06.04 E2
MainMenu → E2 → Alarms →
HB alarm → Hb.P_3
The parameter sets the HB alarm threshold percentage of the current read in HB calibration.
min...max: 0.0...100.0
3.14.7. CT reading in HB calibration
Address
Format
GPC-OP
menu
Acronym
Global / M/E1/E2
GF_eXpress menu
Attribute Retentive Type Unit of mea- surement Default
Single-
node
Multi-
node
Description
1766
742 16 bit
05.04.05
Hb.tA
M
MainMenu → M → Alarms →
HB alarm → Hb.tA_1
R/W
■
Float
(####.#)
A 0.02790 05.05.05 E1
MainMenu → E1 → Alarms →
HB alarm → Hb.tA_2
4838 05.06.05 E2
MainMenu → E2 → Alarms →
HB alarm → Hb.tA_3
The parameter sets the CT reading in HB calibration.
min...max: 0.0...3275.0
3.14.8. VT reading in HB calibration
Address
Format
GPC-OP
menu
Acronym
Global / M/E1/E2
GF_eXpress menu
Attribute Retentive Type Unit of mea- surement Default
Single-
node
Multi-
node
Description
1476
452 16 bit
05.04.06
Hb.tV
M
MainMenu → M → Alarms →
HB alarm → Hb.tV_1
R/W
■
Float
(####.#)
V 0.02500 05.05.06 E1
MainMenu → E1 → Alarms →
HB alarm → Hb.tV_2
4548 05.06.06 E2
MainMenu → E2 → Alarms →
HB alarm → Hb.tV_3
The parameter sets the VT reading in HB calibration.
min...max: 0.0...999.9
3.14.9. Ou.P power in calibration
Address
Format
GPC-OP
menu
Acronym
Global / M/E1/E2
GF_eXpress menu
Attribute Retentive Type Unit of mea- surement Default
Single-
node
Multi-
node
Description
1767
743 16 bit
05.04.07
Hb.Pw
M
MainMenu → M → Alarms →
HB alarm → Hb.Pw_1
R/W
■
Float
(####.#)
% 0.02791 05.05.07 E1
MainMenu → E1 → Alarms →
HB alarm → Hb.Pw_2
4839 05.06.07 E2
MainMenu → E2 → Alarms →
HB alarm → Hb.Pw_3
The parameter sets the Ou.P
power in HB calibration.
min...max: 0.0...100.0
