gefran GPC - Delay Time for HB Alarm Activation; Enabling Calibration; HB Alarm Threshold

81901 “MSW_GPC-40/600A”_03-2021_ENG_page 64
3.14.3. Delay time for HB alarm activation
Address
Format
GPC-OP
menu
Acronym
Global / M/E1/E2
GF_eXpress menu
Attribute Retentive Type Unit of mea- surement Default
Single-
node
Multi-
node
Description
1080
56 16 bit
05.04.02
Hb.t
M
MainMenu → M → Alarms →
HB alarm → Hb.t_1
R/W
■
Unsigned
Short
sec. 52104 05.05.02 E1
MainMenu → E1 → Alarms →
HB alarm → Hb.t_2
4152 05.06.02 E2
MainMenu → M → Alarms →
HB alarm → Hb.t_3
The parameter sets the delay time before the HB alarm is activated. The Hb.t value must be greater than the cycle time of the output with
which the HB alarm is associated.
min...max: 0...999
3.14.4. Enabling calibration
Address
Format
GPC-OP
menu
Acronym
Global / M/E1/E2
GF_eXpress menu
Attribute Retentive Type Unit of mea- surement Default
Single-
node
Multi-
node
Description
1136
112 bit
12.01.05
BIT_
CALIB_
HB
M
MainMenu → M → Expert →
Bit → BIT_CALIB_HB_1
R/W 02160 12.02.05 E1
MainMenu → E1 → Expert →
Bit → BIT_CALIB_HB_2
4208 12.03.05 E2
MainMenu → E2 → Expert →
Bit → BIT_CALIB_HB_3
This bit enables the alarm threshold calibration function for modules GPC-M, GPC-E1 and GPC-E2, depending on the address used.
It should be noted that with a three-phase load, a different value can be set for the A.Hb alarm thresholds. In this mode an unbalanced
three-phase load can be controlled without problems.
Options: OFF = Calibration not enabled
ON = Calibration enabled
3.14.5. HB alarm threshold
Address
Format
GPC-OP
menu
Acronym
Global / M/E1/E2
GF_eXpress menu
Attribute Retentive Type Unit of mea- surement Default
Single-
node
Multi-
node
Description
1079
55 16 bit
05.04.03
A.Hb
M
MainMenu → M → Alarms →
HB alarm → A.Hb_1
R/W
■
Float
(####.#)
A 10.02103 05.05.03 E1
MainMenu → E1 → Alarms →
HB alarm → A.Hb_2
4151 05.06.03 E2
MainMenu → E2 → Alarms →
HB alarm → A.Hb_3
The parameter sets the HB alarm threshold.
min...max: 0.0...3275.0
