3.12.1. Definition of digital input types
Address
Format
GPC-OP
menu
Acronym
Global / M/E1/E2
GF_eXpress menu
Attribute Retentive Type Unit of mea- surement Default
Single-
node
Multi-
node
Description
1409 385 16 bit 04:17:05 tP.dIG Global
MainMenu → Global → Inputs →
Digital inputs → tP.dIG
R/W
■
Unsigned
Short
0
The parameter sets the types of all digital inputs.
Options: 0 = PNP digital inputs
1 = NPN digital inputs
3.12.2. Digital input status
Address
Format
GPC-OP
menu
Acronym
Global / M/E1/E2
GF_eXpress menu
Attribute Retentive Type Unit of mea- surement Default
Single-
node
Multi-
node
Description
1092 68 bit
BIT_
STATUS_
DIG1
Global
MainMenu → Global → Expert →
Bit → BIT_STATUS_DIG1
R
1116 92 bit
BIT_
STATUS_
DIG2
Global
MainMenu → Global → Expert →
Bit → BIT_STATUS_DIG2
R
1091 67 bit
BIT_
STATUS_
DIG3
Global
MainMenu → Global → Expert →
Bit → BIT_STATUS_DIG3
R
1090 66 bit
BIT_
STATUS_
DIG4
Global
MainMenu → Global → Expert →
Bit → BIT_STATUS_DIG4
R
The parameter shows the status of digital input 1, 2, 3 or 4, depending on the address used.
Options: OFF = Digital input off
ON = Digital input active
3.12.3. Digital input status
Address
Format
GPC-OP
menu
Acronym
Global / M/E1/E2
GF_eXpress menu
Attribute Retentive Type Unit of mea- surement Default
Single-
node
Multi-
node
Description
1341 317 16 bit 04.01.07
INPUT_
DIG
Global
MainMenu → Global → Status →
INPUT_DIG
R
The parameter shows the status of the 4 digital inputs with 4-bit status.
Options: bit 0 = INDIG1 status
bit 1 = INDIG2 status
bit 2 = INDIG3 status
bit 3 = INDIG4 status
