gefran GPC - Power Output Percentage; Output Power Offset; Control Output Gradient; Minimum Trigger Output

81901 “MSW_GPC-40/600A”_03-2021_ENG_page 100
3.21.4. Power output percentage
Address
Format
GPC-OP
menu
Acronym
Global / M/E1/E2
GF_eXpress menu
Attribute Retentive Type Unit of mea- surement Default
Single-
node
Multi-
node
Description
1789
765 16 bit
07.02.03
P.PEr
M
MainMenu → M → Controls → P.PEr_1
R/W
■
Float
(####.#)
% 100.02813 07.03.03 E1
MainMenu → E1 → Controls → P.PEr_2
4861 01.04.03 E2
MainMenu → E2 → Controls → P.PEr_3
The parameter sets the percentage of the output power.
min...max: 0.0...100.0
3.21.5. Output power offset
Address
Format
GPC-OP
menu
Acronym
Global / M/E1/E2
GF_eXpress menu
Attribute Retentive Type Unit of mea- surement Default
Single-
node
Multi-
node
Description
1790
766 16 bit
07.02.04
P.oFS
M
MainMenu → M → Controls → P.oFS_1
R/W
■
Float
(####.#)
% 0.02814 07.03.04 E1
MainMenu → E1 → Controls → P.oFS_2
4862 01.04.04 E2
MainMenu → E2 → Controls → P.oFS_3
The parameter sets the offset percentage of the output power.
min...max: -100.0...100.0
3.21.6. Control output gradient
Address
Format
GPC-OP
menu
Acronym
Global / M/E1/E2
GF_eXpress menu
Attribute Retentive Type Unit of mea- surement Default
Single-
node
Multi-
node
Description
1787
763 16 bit
07.02.05
G.Out
M
MainMenu → M → Controls → G.Out_1
R/W
■
Float
(####.#)
%/s 0.02811 07.03.05 E1
MainMenu → E1 → Controls → G.Out_2
4859 01.04.05 E2
MainMenu → E2 → Controls → G.Out_3
The parameter sets the gradient for the control output, i.e., how quickly the final value is reached. The gradient is defined as a percentage
increment per second in relation to the final value to be achieved. Set the parameter to 0 to disable the gradient.
min...max: 0.0...200.0
Example: By setting the gradient to 50%/s the Ou.P output is not implemented instantaneously but gradually. If the power goes from 0%
to 100%, actuation occurs in a linear ramp of 2 seconds duration.
3.21.7. Minimum trigger output
Address
Format
GPC-OP
menu
Acronym
Global / M/E1/E2
GF_eXpress menu
Attribute Retentive Type Unit of mea- surement Default
Single-
node
Multi-
node
Description
1788
764 16 bit
07.02.06
Lo.P
M
MainMenu → M → Controls → Lo.P_1
R/W
■
Float
(####.#)
% 0.02812 07.03.06 E1
MainMenu → E1 → Controls → Lo.P_2
4860 01.04.06 E2
MainMenu → E2 → Controls → Lo.P_3
The parameter sets the minimum output for triggering as a percentage of the maximum achievable value.
min...max: 0.0...50.0
