3.35.21. Status 2 (STATUS2)
Address
Format
GPC-OP
menu
Acronym
Global / M/E1/E2
GF_eXpress menu
Attribute Retentive Type Unit of mea- surement Default
Single-
node
Multi-
node
Description
1656
632 16 bit
01.02.17
STATUS2
M
MainMenu → M → Status → STATUS2_1
R
Unsigned
Short
2680 01.03.17 E1
MainMenu → E1 → Status → STATUS2_2
4728 01.04.17 E2
MainMenu → E2 → Status → STATUS2_3
The parameter shows the status of the device. The individual statuses are highlighted by the corresponding bit.
Options:
bit State of
0 AL1
1 AL2
2 AL3
3 AL4
4 AL.HB PHASE 1 (with three-phase load)
5 AL.HB PHASE 2 (with three-phase load)
6 AL.HB PHASE 3 (with three-phase load)
3.35.22. Status 3 (STATUS3)
See paragraph “3.15.5. Status 3 (STATUS3)”.
3.35.23. Status 4 (STATUS4)
See paragraph “3.16.7. Status reading (STATUS4)”.
3.35.24. Voltage status (VOLTAGE_STATUS)
See paragraph “3.10.7. VOLTAGE_STATUS”.
