81901 “MSW_GPC-40/600A”_03-2021_ENG_page 58
3.13.13. Alarm memory reset
Address
Format
GPC-OP
menu
Acronym
Global /
M/E1/E2
GF_eXpress menu
Attribute
Retentive
Type
Unit of mea-
surement
Default
Single-
node
Multi-
node
Description
1103
79 bit
12.01.03
BIT_
RESET_
AL1_AL8
M
MainMenu → M → Expert →
Bit → BIT_RESET_AL1_AL8_1
R/W
■
2127 12.02.03 E1
MainMenu → E1 → Expert →
Bit → BIT_RESET_AL1_AL8_2
4175 12.03.03 E2
MainMenu → E2 → Expert →
Bit → BIT_RESET_AL1_AL8_3
The parameter allows the memory of all generic alarms to be cleared by changing the state of the bit.
To clear the memory of a specific generic alarm, see parameters dIG.1, dIG.2, dIG.3 and dIG.4 for alarms 1, 2, 3 and 4 respectively.
Options:
OFF = No function
ON = Generic alarms AL1...AL8 are reset
3.13.14. Alarm status (ALSTATE_IRQ)
Address
Format
GPC-OP
menu
Acronym
Global /
M/E1/E2
GF_eXpress
Attribute
Retentive
Type
Unit of mea-
surement
Default
Single-
node
Multi-
node
Description
1342
318 16 bit
AL-
STATE_
IRQ
M
MainMenu → M → Status →
ALSTATE_IRQ_1
R2366 E1
MainMenu → E1 → Status →
ALSTATE_IRQ_2
4414 E2
MainMenu → E2 → Status →
ALSTATE_IRQ_3
The parameter shows the status of generic alarms AL1...AL8 and HB / POWER_FAULT alarms. Bit = 0 indicates the alarm is not active, bit
= 1 indicates the alarm is active.
The following table shows the correspondence between bit and individual alarms.
Options:
bit Description Alarm type
0 Alarm status AL1 Generic alarm
1 Alarm status AL2 Generic alarm
2 Alarm status AL3 Generic alarm
3 Alarm status AL4 Generic alarm
4 Alarm status AL.HB (or phases 1/2/3 if three-phase) or POW-
ER_FAULT
Heater Break Alarm
/ POWER_FAULT
5 Alarm status AL.HB phase 1 (with three-phase load) Heater Break Alarm
6 Alarm status AL.HB phase 2 (with three-phase load) Heater Break Alarm
7 Alarm status AL.HB phase 3 (with three-phase load) Heater Break Alarm
8 Alarm status AL5 Generic alarm
9 Alarm status AL6 Generic alarm
10 Alarm status AL7 Generic alarm
11 Alarm status AL8 Generic alarm
