gefran GPC - Rl.X (MASKOUT_OUT) Status; Alarm Status Stored at Last Activation for Custom Output

81901A “MSW_GPC-40/600A”_03-2021_ENG_page 91
3.19.11. rL.x (MASKOUT_OUT) status
Address
Format
GPC-OP
menu
Acronym
Global / M/E1/E2
GF_eXpress menu
Attribute Retentive Type Unit of mea- surement Default
Single-
node
Multi-
node
Description
1688 664 16 bit 01.01.10
MASK_
OUT
Global
MainMenu → Global → Status →
MASK_OUT
R
Unsigned
Short
The parameter bits show the status of the physical outputs.
Options:
bit Physical output
0 Status OUT1
1 Status OUT2
2 Status OUT3
4 Status OUT5
5 Status OUT6
6 Status OUT7
7 Status OUT8
8 Status OUT9
9 Status OUT10
NOTE: Out 4 does not exist.
3.19.12. Alarm status stored at last activation for custom output
Address
Format
GPC-OP
menu
Acronym
Global / M/E1/E2
GF_eXpress menu
Attribute Retentive Type Unit of mea- surement Default
Single-
node
Multi-
node
Description
1321
297 16 bit
STA-
TUS3_
FOR_
OUT09
M
MainMenu → Global → Expert → Output
Custom → STATUS3_FOR_OUT09_1
R
Unsigned
Short
2345 E1
MainMenu → Global → Expert → Output
Custom → STATUS3_FOR_OUT09_2
4393 E2
MainMenu → Global → Expert → Output
Custom → STATUS3_FOR_OUT09_3
1322
298 16 bit
STA-
TUS3_
FOR_
OUT10
M
MainMenu → Global → Expert → Output
Custom → STATUS3_FOR_OUT10_1
R
Unsigned
Short
2346 E1
MainMenu → Global → Expert → Output
Custom → STATUS3_FOR_OUT10_2
4394 E2
MainMenu → Global → Expert → Output
Custom → STATUS3_FOR_OUT10_3
The parameter shows the STATUS3 status stored at the last activation of custom outputs OUT9 and OUT10.
