gefran GPC - RN - er - DI1 - DI2 LED Function

81901 “MSW_GPC-40/600A”_03-2021_ENG_page 130
3.35.15. RN - ER - DI1 - DI2 LED function
Address
Format
GPC-OP
menu
Acronym
Global / M/E1/E2
GF_eXpress menu
Attribute Retentive Type Unit of mea- surement Default
Single-
node
Multi-
node
Description
1221 197 16 bit 06.08.01 Ld.St Global
MainMenu → Global → Leds → Ld.St
R/W
■
Unsigned
Short
16
1643 619 16 bit 06.08.02 Ld.2 Global
MainMenu → Global → Leds → Ld.2
R/W
■
Unsigned
Short
12
1644 620 16 bit 06.08.03 Ld.3 Global
MainMenu → Global → Leds → Ld.3
R/W
■
Unsigned
Short
15
1645 621 16 bit 06.08.04 Ld.4 Global
MainMenu → Global → Leds → Ld.4
R/W
■
Unsigned
Short
11
This parameter sets the function associated with the RN (Ld.St), ER (Ld.2), DI1 (Ld.3) and DI2 (Ld.4) LEDs, according to the address used.
The function is identified by an index.
Options:
Index Function associated with the LED
0 RUN
1 MAN/AUTO controller
6 INDIG1 digital input configuration
7 Serial dialogue 1
8 OUT 2 GPC-M status
11 INDIG2 digital input configuration
12 Error status
13 Serial dialogue 2
14 INDIG3 digital input configuration
15 INDIG4 digital input configuration
By increasing the index by +16 the LED flashes if active (except index 8).
