81901 “MSW_GPC-40/600A”_03-2021_ENG_page 74
3.15.6. SSR_SHORT alarm status (single-phase configuration or CT phase 1 two-phase or
three-phase configuration)
Address
Format
GPC-OP
menu
Acronym
Global /
M/E1/E2
GF_eXpress menu
Attribute
Retentive
Type
Unit of mea-
surement
Default
Single-
node
Multi-
node
Description
1120
96 bit
BIT_
STA-
TUS_
SSR_
SHORT
M
MainMenu → M → Expert →
Bit → BIT_STATUS_SSR_SHORT_1
R2144 E1
MainMenu → E1 → Expert →
Bit → BIT_STATUS_SSR_SHORT_2
4192 E2
MainMenu → E2 → Expert →
Bit → BIT_STATUS_SSR_SHORT_3
The bit shows the SSR_SHORT alarm status in the single-phase configuration or that of CT phase 1 in two-phase or three-phase configu-
ration.
Options: OFF = Alarm off
ON = Alarm on
3.15.7. SSR_SHORT alarm status (single-phase configuration or CT phase 2 two-phase or
three-phase configuration)
Address
Format
GPC-OP
menu
Acronym
Global /
M/E1/E2
GF_eXpress menu
Attribute
Retentive
Type
Unit of mea-
surement
Default
Single-
node
Multi-
node
Description
1121 97 bit
BIT_
STATUS_
SSR_
SHORT_
PHASE2
M
MainMenu → M → Expert → Bits →
BIT_STATUS_SSR_SHORT_PHASE2_1
R
The bit shows the SSR_SHORT alarm status in the single-phase configuration or that of CT phase 2 in two-phase or three-phase configu-
ration.
Options: OFF = Alarm off
ON = Alarm on
3.15.8. SSR_SHORT alarm status (single-phase configuration or CT phase 3 three-phase
configuration)
Address
Format
GPC-OP
menu
Acronym
Global /
M/E1/E2
GF_eXpress menu
Attribute
Retentive
Type
Unit of mea-
surement
Default
Single-
node
Multi-
node
Description
1122 98 bit
BIT_
STATUS_
SSR_
SHORT_
PHASE3
M
MainMenu → M → Expert → Bits →
BIT_STATUS_SSR_SHORT_PHASE3_1
R
The bit shows the SSR_SHORT alarm status in single-phase configuration or that of CT phase 3 in three-phase configuration.
Options: OFF = Alarm off
ON = Alarm on
