3.31.4. Maximum power feedback correction
Address
Format
GPC-OP
menu
Acronym
Global / M/E1/E2
GF_eXpress menu
Attribute Retentive Type Unit of mea- surement Default
Single-
node
Multi-
node
Description
1757
733 16 bit
09.01.12
Cor.P
M
MainMenu → M → Power controls →
Cor.P_1
R/W
■
Float
(####.#)
% 100.02781 09.02.12 E1
MainMenu → E1 → Power controls →
Cor.P_2
4829 09.03.12 E2
MainMenu → E2 → Power controls →
Cor.P_3
The parameter sets the maximum correction of power feedback. It serves to limit the correction.
min...max: 0.0...100.0
3.31.5. Voltage feedback reference
Address
Format
GPC-OP
menu
Acronym
Global / M/E1/E2
GF_eXpress menu
Attribute Retentive Type Unit of mea- surement Default
Single-
node
Multi-
node
Description
1758
734 16 bit
09.01.14
riF.V
M
MainMenu → M → Power controls →
riF.V_1
R/W
■
Float
(####.#)
V 0.02782 09.02.14 E1
MainMenu → E1 → Power controls →
riF.V_2
4830 09.03.14 E2
MainMenu → E2 → Power controls →
riF.V_3
The parameter sets the voltage feedback reference, i.e., the rated voltage.
min...max: 0.0...999.9
3.31.6. Current feedback reference
Address
Format
GPC-OP
menu
Acronym
Global / M/E1/E2
GF_eXpress menu
Attribute Retentive Type Unit of mea- surement Default
Single-
node
Multi-
node
Description
1758
734 16 bit
09.01.15
riF.I
M
MainMenu → M → Power controls →
riF.I_1
R/W
■
Float
(####.#)
A 0.02782 09.02.15 E1
MainMenu → E1 → Power controls →
riF.I_2
4830 09.03.15 E2
MainMenu → E2 → Power controls →
riF.I_3
The parameter sets the current feedback reference, i.e., the rated current.
min...max: 0.0...3275.0
3.31.7. Power feedback reference
Address
Format
GPC-OP
menu
Acronym
Global / M/E1/E2
GF_eXpress menu
Attribute Retentive Type Unit of mea- surement Default
Single-
node
Multi-
node
Description
1908
884 32 bit
09.01.16
riF.P
M
MainMenu → M → Power controls →
riF.P_1
R/W
■
Float32
(####.#)
kW 00:002932 09.02.16 E1
MainMenu → E1 → Power controls →
riF.P_2
4980 09.03.16 E2
MainMenu → E2 → Power controls →
riF.P_3
The parameter sets the power feedback reference, i.e., the rated power.
The LSW data in Word format (16 bits) is available at address 736 (1760 - 2784 - 4832).
min...max: 0.00
...1500.00
