gefran GPC - Direct Setting of a Normal or Symmetrical Alarm

81901A “MSW_GPC-40/600A”_03-2021_ENG_page 53
3.13.8. Direct setting of a normal or symmetrical alarm
Address
Format
GPC-OP
menu
Acronym
Global / M/E1/E2
GF_eXpress menu
Attribute Retentive Type Unit of mea- surement Default
Single-
node
Multi-
node
Description
1072
48 bit
BIT_
AL1_
NOR_
SYM
M
MainMenu → M → Expert →
Bit → BIT_AL1_NOR_SYM_1
R/W
■
OFF2096 E1
MainMenu → E1 → Expert →
Bit → BIT_AL1_NOR_SYM_2
4144 E2
MainMenu → E2 → Expert →
Bit → BIT_AL1_NOR_SYM_3
1080
56 bit
BIT_
AL2_
NOR_
SYM
M
MainMenu → M → Expert →
Bit → BIT_AL2_NOR_SYM_1
R/W
■
OFF2104 E1
MainMenu → E1 → Expert →
Bit → BIT_AL2_NOR_SYM_2
4152 E2
MainMenu → E2 → Expert →
Bit → BIT_AL2_NOR_SYM_3
1062
38 bit
BIT_
AL3_
NOR_
SYM
M
MainMenu → M → Expert →
Bit → BIT_AL3_NOR_SYM_1
R/W
■
OFF2086 E1
MainMenu → E1 → Expert →
Bit → BIT_AL3_NOR_SYM_2
4134 E2
MainMenu → E2 → Expert →
Bit → BIT_AL3_NOR_SYM_3
1096
72 bit
BIT_
AL4_
NOR_
SYM
M
MainMenu → M → Expert →
Bit → BIT_AL4_NOR_SYM_1
R/W
■
OFF2120 E1
MainMenu → E1 → Expert →
Bit → BIT_AL4_NOR_SYM_2
4168 E2
MainMenu → E2 → Expert →
Bit → BIT_AL4_NOR_SYM_3
The parameter sets the normal or symmetrical mode for alarms 1, 2, 3 and 4, depending on the address used. For further information, see
paragraph “4.4.1. Generic alarms AL1...AL8”.
Options: OFF = Normal alarm
ON = Symmetrical alarm
