gefran GPC - E2 Energy Consumed; E1 Three-Phase Energy Consumed; E2 Three-Phase Energy Consumed; E1 Energy Consumption Meter Reset

81901 “MSW_GPC-40/600A”_03-2021_ENG_page 36
3.11.6. E2 energy consumed
Address
Format
GPC-OP
menu
Acronym
Global / M/E1/E2
GF_eXpress menu
Attribute Retentive Type Unit of mea- surement Default
Single-
node
Multi-
node
Description
1534
510 32 bit
01.02.10
Ld.E2
M
MainMenu → M → Status → Ld.E2_1
R
■
Unsigned
Int
kWh2558 01.03.10 E1
MainMenu → E1 → Status → Ld.E2_2
4606 01.04.10 E2
MainMenu → E2 → Status → Ld.E2_3
This parameter shows the value of the E2 energy consumed since the meter was switched on or last reset.
3.11.7. E1 three-phase energy consumed
Address
Format
GPC-OP
menu
Acronym
Global / M/E1/E2
GF_eXpress menu
Attribute Retentive Type Unit of mea- surement Default
Single-
node
Multi-
node
Description
1565 541 32 bit 01.01.05 Ld.E1.t Global
MainMenu → Global → Status → Ld.E1.t
R
■
Unsigned
Int
kWh
The parameter shows the value of the E1 three-phase energy consumed since the meter was switched on or last reset, which is the sum
of the E1 energies consumed on the 3 individual phases.
3.11.8. E2 three-phase energy consumed
Address
Format
GPC-OP
menu
Acronym
Global / M/E1/E2
GF_eXpress menu
Attribute Retentive Type Unit of mea- surement Default
Single-
node
Multi-
node
Description
1524 500 32 bit 01.01.06 Ld.E2.t Global
MainMenu → Global → Status → Ld.E2.t
R
■
Unsigned
Int
kWh
The parameter shows the value of the E2 three-phase energy consumed since the meter was switched on or last reset, which is the sum
of the E2 energies consumed on the 3 individual phases.
3.11.9. E1 energy consumption meter reset
Address
Format
GPC-OP
menu
Acronym
Global / M/E1/E2
GF_eXpress menu
Attribute Retentive Type Unit of mea- surement Default
Single-
node
Multi-
node
Description
1138
114 bit
BIT_
RESET_
LDE1
M
MainMenu → M → Expert →
Bit → BIT_RESET_LDE1_1
R/W OFF2162 E1
MainMenu → E1 → Expert →
Bit → BIT_RESET_LDE1_2
4210 E2
MainMenu → E2 → Expert →
Bit → BIT_RESET_LDE1_3
The parameter sets the reset function of the E1 energy meter.
Options: OFF = Function is disabled
ON = The function is enabled. The meter Ld.E1 is reset to zero.
